Description
7 BBL Red Copper Brewhouse for Pub and Craft Production
This 7 bbl (1000 L) red copper brewhouse is built for breweries and beer pubs that need a visible, practical brewhouse without turning the cellar into a stainless showroom. Copper is used on the kettle and lauter/whirlpool where heat transfer and presentation matter; the hot liquor tank, piping and frames are normally stainless. We confirm batch size, heating method and platform height before fabrication because a pub with low ceiling clearance cannot use the same layout as a production brewery.
Material choices are straightforward. Product-contact stainless is SUS304 as standard; SUS316L is available for aggressive cleaning regimes or higher chloride exposure. Copper vessels are formed, welded and dressed, then passivated or lined as needed at the customer’s specification. Welds on stainless parts are ground and polished to reduce soil traps. Gaskets, clamps and valves are selected for steam, hot water and CIP conditions. We pressure-test jackets and vessels before shipment and match safety valves to the working pressure stated on the nameplate.
For a 7 bbl system, a typical layout includes mash/lauter tun, brew kettle/whirlpool, hot liquor tank, heat exchanger, pumps and control panel. Pub systems often use direct-fired or electric heating and compact footprints; production breweries may specify steam. CIP connections should be planned at the design stage, not added after piping is fixed. Cooling water and wort lines need service access.
| Item | Specification |
|---|---|
| Batch size | 7 bbl / 1000 L |
| Vessel material | Red copper + SUS304/SUS316L |
| Heating | Steam, electric or direct fire |
| Control | Manual or PLC |
FAQ
Can it fit a beer pub? Yes, but send ceiling height, floor loading and service clearance first.
Copper or stainless? Copper suits visible brewhouses; stainless is easier for utility areas.
What should I prepare for a quote? Batch size, beer styles, heating source, tank count and room dimensions.
Tell us your batch size, beer type, number of fermentation tanks and available space. We can recommend the tank volume, cooling area and configuration for your brewery.
