Description
Large-format brewery equipment for repeatable commercial batches
Our 10,000 L and 20,000 L brewery systems are built for breweries moving from pilot batches to scheduled commercial production. Tank volume, jacket area, pump sizing and CIP routing are matched to batch size, beer style and utility capacity. We review your brewhouse schedule before recommending tank count; a 20,000 L fermenter that cannot cool within your glycol window creates more problems than it solves.
Materials, welding and finish
Product-contact surfaces use SUS304 as standard. SUS316L is available for high-chloride water, sour programs or tighter corrosion margins. We control weld maps, purge gas and pickling/passivation. Interior welds are ground and polished to Ra ≤0.8 µm where required; exterior welds are cleaned without over-finishing. Cone angle, dish heads, manway placement, dry-hop port and sample valve location are fixed at drawing approval. Jackets are dimple or laser-welded according to pressure and cooling load. Each jacket and vessel is pressure-tested before shipment.
Process integration and site fit
CIP supply, return, CO2, blow-off and glycol connections are arranged around your floor layout. Ports are labeled and supplied with a piping schedule so your contractor can tie in without guesswork. Relief valves are sized to the vessel rating, not just working pressure. For 10,000–20,000 L units, confirm door width, ceiling height and floor loading before order release.
Technical specifications
| Capacity | 10,000 L / 20,000 L |
| Material | SUS304 / SUS316L |
| Interior finish | Ra ≤0.8 µm |
| Cooling jacket | Dimple or laser welded |
| Design pressure | 1.5–3 bar optional |
| Test pressure | 1.5× design |
| Insulation | PU foam |
| CIP | Spray ball |
| Manway and port layout | Custom |
| Control | PID glycol solenoid optional |
Practical questions
How do I choose between 10,000 L and 20,000 L? Start with cast-out volume, headspace, fermentation days and tank count. A larger tank only helps if your brewhouse and glycol system can support it.
Why use a conical bottom? It helps yeast recovery, trub separation and cleaning. Cone angle and outlet size depend on yeast strain and batch practice.
Can the tank handle dry hopping? Yes. We add a dedicated port and consider cleaning access around it.
What information do we need for a quote? Batch size, beer type, tank count, available space, glycol capacity and CIP preferences.
Tell us your batch size, beer type, number of fermentation tanks and available space. We can recommend the tank volume, cooling area and configuration for your brewery.
