Description
This 2000L turnkey system is built around the fermentation tanks, not the other way around. We size the brewhouse to match the tank farm and the cooling load you can actually support. The tanks are 2000L working volume, 304 or 316L stainless, with dimpled cooling jackets and 2B interior finish. Isochoric operation means the tank is rated to hold pressure at fermentation temperature without CO2 blow-off, which matters if you plan to carbonate in-tank or package without a bright beer tank.
Shell thickness starts at 3 mm for the inner vessel; we go to 4 mm on tanks over 2 bar working pressure. All welds are TIG, ground and pickled on product contact surfaces. When you specify 316L, we change the jacket and fittings too—not just the shell. That detail shows up in the quote, and it should.
Small craft breweries often order three or four 2000L fermenters against a 10–15 BBL brewhouse. Commercial operations use them as finishing tanks ahead of filtration. The cone angle, racking arm height, and CIP spray ball position are set per your brewhouse layout, not off a catalog drawing.
Cooling jacket surface area is calculated from your crash-cooling target, not tank volume alone. If you plan to drop from 68°F to 34°F in 24 hours, tell us. The glycol supply temperature and jacket coverage change accordingly.
Pressure relief is set at 2.5 bar unless your process requires otherwise. CIP return line size, sample valve height, and dry-hop port location are confirmed before fabrication. We do not ship until the P&ID is signed off.
| Working volume | 2000 L |
|---|---|
| Material | SUS304 / 316L |
| Inner shell | 3–4 mm |
| Cooling | Dimpled jacket, 2 zones |
| Design pressure | 2.5 bar |
| Finish | 2B interior, pickled welds |
Tell us your batch size, beer type, number of fermentation tanks and available space. We can recommend the tank volume, cooling area and configuration for your brewery.
