Description
We build the 2000L–5000L craft brewery system around cellar duty, not a catalog headline. A fermenter has to hold temperature through active fermentation, drop yeast from a cone, accept CIP, and stay easy to inspect after months of service. The tank can be supplied as a single unit or as part of a matched brewery package with control panel, cooling jacket, racking arm, dry hop port and pressure relief.
Material choice starts with the product contact side. SUS304 covers most ale and lager duty; 316L is used when chloride exposure, cleaning chemicals or customer standards call for it. We TIG weld internal seams, polish wetted surfaces, and pressure-test jackets and tank shells before shipment. Insulation and outer cladding matter in cold cellars; poor cladding shows up as condensation and unstable temperature. Cone angle, jacket area and valve height are set from batch size and floor layout.
Control is practical: temperature probes, glycol valve control, pump logic and safety interlocks. Working pressure and relief valve sizing must match the tank design and local code. CIP usually runs through a spray ball, with return path and drain sized so the pump does not flood the cone.
Small brewhouses often choose 2000L tanks for pilot and seasonal runs; 5000L tanks suit higher turnover and fewer SKUs. Tank count should follow brew length, fermentation days and packaging rhythm, not just annual hectoliters.
Technical specifications
| Item | Range or detail |
|---|---|
| Nominal volume | 2000L to 5000L |
| Material | SUS304 or 316L contact side |
| Cooling | Glycol jacket, insulated shell |
| Control | Temperature and pump logic panel |
| Connections | CIP, racking, carbonation, relief |
| Finish | Polished wetted surfaces |
FAQ
Can one control panel run several tanks? Yes, if glycol valves, probes and pump capacity are planned as a cellar group. We size the panel from tank count and simultaneous cooling load.
Do we need a conical bottom? For yeast recovery and dry hopping, yes in most ale cellars. Flat-bottom tanks can work for short-turnaround or specialty service if cleaning access is resolved.
What details are needed for a quote? Batch volume, beer style, tanks per brew, glycol supply temperature, floor space, voltage, CIP method and local pressure rules.
Tell us your batch size, beer type, number of fermentation tanks and available space. We can recommend the tank volume, cooling area and configuration for your brewery.
