Description
CIP systems sized for brewery duty
We build 50 L, 100 L, and 200 L Clean-in-Place systems for breweries and process plants that need repeatable cleaning of tanks, lines, and fill heads. CIP circulates detergent, rinse water, and optional sanitizer through the wetted circuit at controlled temperature, flow, and time. That reduces tear-down cleaning and helps keep wash cycles consistent.
A common cycle is pre-rinse, alkaline wash, intermediate rinse, acid wash when needed, final rinse, and sanitizer. Supply and return pumps keep the loop moving; temperature, flow, pressure, and level instruments confirm the run. We configure single-, double-, triple-, or multi-tank units with caustic, acid, and hot water tanks, electric or steam heating, stainless piping, valves, and manual, semi-automatic, or PLC control. These are options, not standard on every unit; we confirm scope before quoting.
Sizing starts with your tank list, pipe diameter and length, spray ball count, soil type, and target cycle time. The 50 L system fits pilot brewhouses and small fermenter sets. 100 L and 200 L units suit larger brewhouses, bright tanks, and transfer lines. Do not size by tank volume alone. Pump head, return pressure, and heating recovery often determine whether the wash holds temperature.
Technical specifications
| Item | Scope |
|---|---|
| Cleaning tank capacity | 50 L, 100 L, 200 L; custom |
| Number of tanks | 1 to 4 or more, project-dependent |
| Stainless grade | 304 or 316L as specified |
| Heating | Electric or steam |
| Pump flow and pressure | Sized to circuit; confirm at inquiry |
| Operating temperature | Controlled wash/rinse range |
| Control | Manual, semi-automatic, or PLC |
| Cleaning circuits | Single or multiple |
| Power | Customer voltage/frequency |
| Dimensions | Layout-specific drawing |
| Custom options | Tank size, heating, pumps, instruments, skid, controls |
Applications
Dairy, beverage, brewery, distillery, sauce, liquid food, cosmetics, and pharmaceutical production use CIP for tanks, piping, fillers, and process equipment. Duty varies with soil, surface finish, and circuit layout; review site requirements directly.
Common questions
Can one unit clean fermenters and transfer lines? Yes, if pump head, circuits, and valving match both duties.
Do we need acid and caustic tanks? Not always. Soil and water chemistry decide.
What speeds a quote? Tank volumes, pipe sizes, soil, heat source, voltage, automation, and location.
Request a recommendation
Send your industry and product, tank and piping details, required cleaning capacity, heat source, automation level, stainless grade, and installation location. We will review the duty and provide a factory-direct recommendation, engineering support, and customized quotation.
