Description
We build this 2000 L / 20 BBL fermenter for breweries that need a working tank between pilot batches and full production. In a 20 BBL brewhouse it can act as a primary fermenter; in smaller breweries it is often a double-batch tank. Typical working volume is 1,600–1,800 L, leaving headspace for krausen, dry hopping, and pressure transfer. High-gravity or heavily dry-hopped beers need more headspace, so confirm the batch size before fixing the tank volume.
Product contact is normally SUS304, with 316L available when cleaning chemistry or site conditions justify it. We TIG-weld internal seams, pickle and passivate weld zones, and polish product contact areas to a sanitary finish. Dimple jackets on the cone and lower body hold fermentation temperature; polyurethane insulation and stainless cladding reduce heat pickup. Standard fittings include conical bottom, racking arm, sample valve, pressure gauge, safety valve, CIP spray ball, and tri-clamp ports for beer, CIP, and glycol. Port orientation and valve layout are matched to your brewery line, not forced to a fixed drawing.
| Item | Specification |
|---|---|
| Nominal capacity | 2000 L / 20 BBL / 20 HL |
| Working volume | Approx. 1,600–1,800 L |
| Material | SUS304 standard; SUS316L optional |
| Cooling | Dimple jacket on cone and body |
| Pressure | Design pressure configured to order |
| Certification | CE documentation available |
Pressure rating is a practical safety item. A 20 BBL tank may be rated for 2 bar working pressure, but the safety valve, regulator, and CIP return path must match that rating. Do not pressure-transfer or carbonate in a tank unless its design pressure is confirmed.
FAQ
How do I choose capacity? Start with batch size, headspace, and tank count. A 20 BBL tank suits 15–18 BBL packaged batches in many setups.
Why a conical bottom? It supports yeast recovery, trub removal, and cleaner transfers.
How is CIP handled? A spray ball, CIP return, and matched tri-clamp piping let you circulate cleaning solution without opening the tank.
What about small versus commercial breweries? Brewpubs often prioritize simple cleaning and yeast recovery; larger breweries may specify 316L, higher polish, larger dry-hop ports, or sensor-ready fittings.
Tell us your batch size, beer type, number of fermentation tanks and available space. We can recommend the tank volume, cooling area and configuration for your brewery.
