Description
Where a 1000 L conical fits
Most 1000 L tanks we build go to brewpubs casting 10 hl brews and packaging 20–30 hl a week. It is a single-batch fermenter: one brew, one tank, no blending between vessels. If your brewhouse knocks out 20 hl, step up to 2000 L instead of filling this one twice.
Fabrication details that end up in the beer
The wetted shell is SUS304, 3 mm, 2B finish polished to Ra ≤ 0.8 µm. We TIG weld with argon backing, then pickle and passivate — the crevice under a badly purged weld is where lactobacillus settles in. 316L earns its upcharge when you run sours, heavy dry hopping, or long hot caustic cycles.
A 60° cone drops trub and yeast without a rake. Dimple jackets on the cone and lower cylinder give about 1.2 m² of cooling area; with 4 °C glycol that crashes an ale in under a day. Lagers want the full jacket and a slower ramp.
Pressure and spunding
Working pressure is 0.2 MPa, hydro-tested at 0.3 MPa. A spunding valve lets you carbonate on residual CO2 late in fermentation and cuts gas purchases. Set the PRV at 2.2 bar, and never isolate the CIP arm without a gauge in the line.
Ports and connections
Standard layout: racking arm, sample valve, dry hop port, CIP spray ball, 25 mm glycol in/out, and a 2\” bottom outlet with butterfly and yeast harvest. Tell us your thread standard — DIN, Tri-Clamp, or RJT — and we machine to it.
Specifications
| Gross volume | 1200 L |
| Working volume | 1000 L |
| Inner shell | SUS304, 3 mm |
| Cooling jacket | Dimple, approx. 1.2 m² |
| Insulation | 80 mm PU |
| Cone angle | 60° |
| Working / test pressure | 0.2 MPa / 0.3 MPa |
| Interior finish | Ra ≤ 0.8 µm |
| Glycol connections | 25 mm |
| Bottom outlet | 2\” Tri-Clamp |
Questions we get before an order
Can it ferment lagers? Yes, with the full jacket and 2 °C glycol supply. Diacetyl rests run longer in a 1000 L cone than in a 500 L tank, so plan the schedule accordingly.
Is 316L necessary? Only for sour programs, high-chloride water, or aggressive caustic regimes.
How is CIP handled? Spray ball on a dedicated line, 1.5–2% caustic at 60–80 °C, 15 minutes, then acid and a sanitizer cycle.
Can it work as a bright tank? Yes if you order the higher pressure rating and add a carbonation stone.
Tell us your batch size, beer type, number of fermentation tanks and available space. We can recommend the tank volume, cooling area and configuration for your brewery.
