Description
The step from 2000L to 3000L is rarely about the vessel alone. It moves the cold room footprint, chiller duty, the number of fermenters you can run against one brewhouse, and how much beer waits in the bright tank before packaging. We build these as single-wall or jacketed units, and the volume should follow your weekly throughput rather than a catalog page.
Fabrication decisions that reach the glass
Shell and cone in SUS304 as standard. We switch the product contact surface to 316L when you run high-acid or sour programs, or when the same tank doubles as a bright beer tank. Interior welds are ground, pickled and passivated, with 0.4–0.8 µm polish on the cone and lower shell where yeast and trub settle.
Cooling comes from dimple or pillow jackets on the cone and lower cylinder, sized against your glycol supply temperature. Undersized jackets are the usual reason a 3000L tank will not crash cool overnight. Working pressure runs 0.15–0.3 MPa with a matching relief valve and a separate vacuum relief, since a blocked CIP return can pull a tank down faster than any overpressure event. Cleaning uses a rotating spray ball under the top manway; wort, CIP return, racking arm and glycol in/out are 1.5 in TC. Legs are adjustable, and we set outlet height to suit your floor drain and pump arrangement.
Specifications
| Model | Total volume | Working volume | Inner shell | Jacket | Design pressure |
|---|---|---|---|---|---|
| 2000L | 2400L | 2000L | SUS304 / 316L | Cone + 1 cylinder zone | 0.3 MPa |
| 2500L | 3000L | 2500L | SUS304 / 316L | Cone + 2 cylinder zones | 0.3 MPa |
| 3000L | 3600L | 3000L | SUS304 / 316L | Cone + 2 cylinder zones | 0.3 MPa |
Questions buyers ask before ordering
Conical or dish bottom? A 60° cone sheds yeast cleanly and lets you harvest, so it suits ale and lager programs with repitching. Dish bottoms make sense for serving tanks where yeast drop is not the point.
Is 316L necessary? Not for standard wort. It earns its price with sour beer, kombucha, and any vessel that sees aggressive cleaning cycles.
Can ports be changed? Yes — dry hopping, sample valve position, carb stone and level sensor taps are set at drawing approval, not after fabrication.
Tell us your batch size, beer type, number of fermentation tanks and available space. We can recommend the tank volume, cooling area and configuration for your brewery.
