Description
What a Combi Tank Actually Does in a Winery
A combi tank handles two jobs in the same vessel: alcoholic fermentation and later storage. The 7000 L working volume sits under an 8000 L total capacity, so there is roughly 1000 L of headspace for must expansion, cap management, and pump-over without foam reaching the CIP spray ball. Cellars that bottle in stages usually pick this configuration so a tank does not sit idle from November to March.
Build Details That Matter
Shell and cone are formed from 3 mm SUS304 plate; 316L is available when the tank will see high-acid musts, extended lees contact, or aggressive acidified cleaning. The dimple cooling jacket is welded to the shell and lower cone, with separate inlet and outlet zones if you want independent control of the cone during cold stabilization. Insulation is 80–100 mm polyurethane poured or foamed in place, then clad in stainless sheet — polyurethane is the reason a tank holds 8 °C overnight in a warm cellar without the chiller short-cycling.
Interior welds are ground flush and passivated, with a mechanical polish to Ra ≤ 0.8 µm on wetted surfaces. We pressure-test every jacket and vessel before insulation goes on, since a leaking dimple weld after cladding is a scrap tank.
Typical Applications
Small estate wineries running 5–10 t harvests, custom crush facilities, and fruit wine or cider producers. Conical-bottom units suit red fermentation with racking and lees removal; flat or shallow-cone bottoms are common for white juice settling and storage.
Specifications
| Total volume | 8000 L |
|---|---|
| Working volume | 7000 L |
| Shell material | SUS304 (SUS316L optional) |
| Insulation | 80–100 mm PU, stainless cladding |
| Cooling | Dimple jacket, glycol/water, 2 bar working |
| Design pressure | 0.2–0.5 bar; vacuum/pressure relief valve fitted |
| Surface finish | Inner Ra ≤ 0.8 µm, passivated |
| Fittings | Top manway, CIP spray ball, thermowell, sample valve, racking arm, 1.5 in. butterfly outlets |
FAQ
Can it ferment reds and store whites? Yes, but confirm the cone angle and jacket zoning first — a 60° cone drains lees better than a shallow one.
How is CIP handled? A rotating spray ball on the top manway plus a 1.5 in. drain gives full coverage at 2–3 bar supply pressure.
Fixed or removable top? Removable tops simplify inspection; fixed tops with a 400 mm manway cost less and seal better.
Tell us your batch size, wine type, number of tanks and available ceiling height. We can recommend the tank volume, cooling area and configuration for your winery.
Related products
Wine Fermentation & Storage Tanks 1000L–10000L Stainless Steel for Wineries
Stainless steel wine fermentation and storage tanks from 1,000 L to 10,000 L, built in SUS304 or 316L with dimple-plate cooling jackets, CIP spray balls and conical or flat bottoms. Sized for small cellars through commercial wineries, with pressure rating, jacket area and fittings matched to your batch size, wine style and glycol supply.
2000L Custom Wine Fermenter Tank with Cooling Chiller Vessel
A 2000L wine fermenter tank for small wineries, brewpubs, and contract producers. Built in SUS304 or SUS316L with glycol cooling jackets, sanitary welds, CIP fittings, and customizable cone, manway, and ports. Use it for fermentation, cold stabilization, or storage. Share batch size, wine type, tank count, and space so we can recommend the right cooling area and configuration.
1500L Grape Wine Fermentation Tank with Cooling Jacket | Custom Build
Built for small wineries and trial lots, this 1500 L jacketed fermenter handles roughly 12.8 US barrels per batch. It uses a dimpled cone and lower-cylinder jacket sized for real crash cooling, 304 or 316L stainless construction, and a 60° conical bottom with racking arm. Configured around your glycol loop, CIP setup and floor space before shipping.
1000L to 10000L Sparkling Wine Fermentation and Storage Tank with Cooling Jacket
Sparkling wine fermentation and storage tanks from 1000 L to 10000 L, built in SUS304 or SUS316L with dimple glycol jackets, adjustable pressure relief, and CIP spray ball. Sized for Charmat-style secondary fermentation and chilled storage, with polished wetted surfaces and insulated cladding for stable temperature control in the cellar.
1000L-3000L Open Top Wine Fermentation Tank | Spiral Channel Cooling Jacket
